Electric heating system

Heating XL-pipe

Heating XL-pipe
Iconic product in electric floor heating system that came out in the market in 2007, after 3 years of development from 2003 to 2006,
Products of Enerpia’s electric heating system use boiling water, which make them energy-efficient and easy to maintain.
Internal structure map of the Heating XL-pipe
Eco-friendly advanced heating system that maximizes heating efficiency by using the heat and expansion pressure generated from the heat of a special heat transfer medium when the
electric heating wires inside the sealed XL pipe are heated, which does not require a boiler (a means of heating the floor) or a circulation motor (a means of deliberately circulating hot water).
BUSINESS BASED ON TRUST
Innovative technology ensures safe living.
SMART FACTORY SYSTEM Implemented Smart Factory Digital automation solutions that combine advanced process with cutting-edge ICT!
Enerpia’s smart factories accumulate all the important data for production, inspection, and shipment in our in-house servers for careful analysis.
High-quality construction with unrivaled technology We invite you to meet Enerpia’s products that
ensure customer satisfaction with construction techniques built
with the know-how and patented technology accumulated over the years.
Why choose Enerpia Heating XL-pipes?
  • A product that implements ondol-style heating through an electric floor heating system.
  • All electrical energy is converted into heat for 100% use in actual heating.
  • Heat accumulation effect guarantees long heating with less energy usage.
  • Reduce energy usage using the heat transfer effect.
  • A heating system that does not produce freeze, smoke, or gas.
  • No noise and excellent space managementas there is no boiler room.
  • A remodeling system that supports perfect repairs without dismantling the existing floor.
  • Safe usage without additional maintenance.
  • No noise and excellent space management as there is no boiler room.
Installation recommended in various places.
Applicable with any floor finishing material. The Heating XL-pipes is more economical when used longer, thanks to the heat storage effect.
  • Religious facilities
  • Accommodations
  • Educational facilities
  • Dormitory
  • Lecture rooms
  • Restaurants
Special repair method of the Heating XL-pipe
  • Simple after-sales service
    There is no need to relocate furniture and the finishing materials are not damaged
    as only the maintenance box is opened for remodeling.
Heat wire remodeling structure

It is a technology that maintains the existing piping and inserts heat medium and heating wire inside the piping.

  • High efficiency
    Heat efficiency can be improved
  • Compatibility with existing X-L pipes
    All places that uses existing XL piping
    can replace to the Heating XL-pipe.
Calculation of electric capacity per unit area of Heating XL-pipe
Construction area basis
Total required area(m²)
Expected operating power(W/h)
* The data are for reference only and may differ according to the site condition
Heating XL-pipe Specification table
model number product specification rated power power consumption heating area(㎡) average power consumption
DW-005 7m×15A 40W/m
Construction Intervals
20~25cm		 280Wh 1.65 170Wh/㎡
DW-010 14mx15A 560Wh 3.30
DW-015 21mx15A 840Wh 4.95
DW-020 28mx15A 1,120Wh 6.60
DW-025 35mx15A 1,400Wh 8.25
DW-030 42mx15A 1,680Wh 9.90
DW-035 49mx15A 1,960Wh 11.55
DW-040 56mx15A 2,240Wh 13.20
DW-045 63mx15A 2,520Wh 14.85
DW-050 70mx15A 2,800Wh 16.50
DW-055 77mx15A 3,080Wh 18.15
DW-060 84mx15A 3,360Wh 19.80
DW-065 91mx15A 3,640Wh 21.45
※ Product specification (length), power consumption, and heating area can be order-made.
Heating XL-pipe Construction
Main construction subsidiary materials of the Heating XL-pipe
  • wire mesh
  • silver film insulation
  • maintenance box
Certificates of Heating XL-pipe

Patent No. 10-0805702

Patent No. 10-0805703

Utility Model No. 20-0442474

Russia GOST

CE

KTC Test report

Quality certification (Q-Mark)

CU Russia

Competitive bidding registration

Heating cable test report
  • Heating XL-pipe Brochure
  • Heating XL-pipe Specification
  • Heating XL-pipe
    Reduce energy usage using the heat transfer effect, A remodeling system that supports perfect repairs without dismantling the existing floor.


    The shielded electric heating hot water pipe is an eco-friendly advanced heating system that maximizes heating efficiency by using the heat and expansion pressure generated from the heat of a special heat-transfer fluid when the electric heating wires inside the sealed XL pipe are heated, which does not require a boiler (a means of heating the floor) or a circulation motor.
